Alarmsense Detector Base Wiring Diagram

After the detector base is wired and attached to the electrical box, make sure that the shorting spring is in contact with the base of terminal 3. This detector base can be made tamper resistant so the detector cannot be detached without the use of a tool. The 4098 duct detector/sensors (see figure 1) are designed to sample air and detect smoke in air ducts.

Alarmsense detector base wiring diagram. After the detector base is wired and attached to the electrical box, position the shorting spring against terminal 3. This information is useful for setting the detector head address and for verification of the detector type required for that location. For example, a room in a house of multiple occupation which is occupied by a heavy smoker. Wiring instructions caution do not loop wire under terminals.

Before wiring the detector loops. Continues to work during unauthorised removal of detectors; Once all detector bases have been wired and mounted, and the loop wiring has been checked, the detector heads may. Break wire run to ensure supervision of connections.

Designed to work with apollo’s alarmsense range of detectors, call points, sounders and beacons. Quick connection via square cable clamps ; An integrating optical smoke detector. Detects the removal of a detector head and reports a fault;

Housed in a pure white polycarbonate moulding. Bayonet slot, low insertion force for detectors;. The base is used for installing detectors that do not require an integral sounder or sounder visual indicator. I think a competent fire alarm engineer is required for this situation.

Most conventional fire systems work with two pairs of wires per zone: The negative line is connected to the l1 in and l1 out on the moulding terminals. An alarmsense detectors can only be mounted into the alarmsense base. One pair for detection devices;

The apollo alarmsense system allows compatible smoke and heat detectors, call points, sounders, sounder/ beacons and alarm relays to be connected to a single pair of wires rather than having two pairs of wires, one for detection devices and one for sounders and relays. End of line resistor as recommended by the panel manufacturer. Apollo series 65 relay base wiring diagram. Available with 2, 4 and 8 alarmsense zone circuits.

The 12v relay base is operated by the detector and must therefore be fitted with a series 65 smoke or heat detector to function. It is not compatible with other ranges of detectors and must be used with alarmsense compatible control equipment. Fig1.alarmsense zone wiring diagram zone 1 key: Many twin wire systems use reverse polarity but apollo alarmsense uses voltage changes, in a quiescent state 12v runs through the system, device activation causes the panel to raise the voltage to 24v to activate the sounders.

Sounder/sounder beacon base dil switch position: Wiring diagram for a typical 120vac detector system: The 4098 duct detector/sensors are available in the following configurations: Accepts up to 2.5mm² cables;

Do not connect any field wiring to the l1 out terminal of the alarmsense base. Use the slot in the retaining clip to hold the spring against the terminal, as shown in. The base is designed to operate over a voltage range of 9v to 15v dc. Ducted prior to connection of alarmsense devices.

The zone wiring of the detector base should be checked before installing the smoke detector head.
